Automatic Run-out Inspection Station
Automatic Run-out Inspection Station
DIN-KO's run-out inspection station features high-precision measurement, customizable positioning options, manual/automated rotation systems, data processing and display, and versatile applications. It is commonly used to inspect the concentricity, roundness, and balance of circular or rotating components such as shafts, wheels, discs, and gears.
Run-out inspection is crucial for ensuring product accuracy, reducing wear and vibration, and extending equipment lifespan.
The automatic run-out inspection station requires only initial positioning before performing batch inspections. The equipment utilizes the Japanese inspection probe "GT-10 Multifunctional Digital Contact Sensor," achieving a repeatability accuracy of up to 3μm and a maximum measurement range of 600mm. It can be paired with mechanical grippers to reduce manual loading efforts. The PLC panel offers intuitive operation and monitoring, aligning with the need for simplified equipment operation.
Dimensions: 1004mm × 1144mm × 1375mm
